Video Surveillance Equipment
Fixed
TORUSS-LR2000
Long-range high-resolution video surveillance equipment
- Intelligent video surveillance equipment optimized for day, night and long-distance sea monitoring by applying HD high-resolution thermal imaging cameras and implementing radar-linked slew-to-Cue systems
- Features
-
- Application of HD high resolution thermal imaging camera.
- Implementation of a radar-linked through-cue system.
- Intelligent coastal surveillance systems and long-range observation equipment for day and night seas.
- Equipped with AI deep learning-based target detection and tracking.
- It is easy to maintain with the image optical device components (3 types) and the modularization of the high-precision drive device.
- Target position can be measured with laser range finder (LRF).
- Long-distance target precision orientation with high precision drive and image stabilization function.
- State major facilities/industrial facilities/port facilities/state and night monitoring of island areas.
Key Performance
1) EO camera
- Resolution: 1920×1080 = 5M Pixels
- Optical lens focal length: 1000mm or more (Full HD IP Camera)
- Focus Control: Auto Focus / Manual Adjustment
2) IR camera
- Resolution: 1280×720
- Focus distance: 1,200 mm (22x optical, 16x digital)
- Focus Control: Auto Focus / Manual Adjustment
Appearance and certification status
- Operating temperature: -32°C to +43°C
- Authentication: IP66, MIL-STD810G
- External dimension: 488(W) × 405(H) × 599(D)
- Weight: 36 kg
